Quick Answer

Grinding problems are usually tooling or technique issues rather than defects in the concrete. Match the blade bore exactly to your saw spindle — common sizes are 20 mm, 22.23 mm (7/8"), 25.4 mm (1") and 30 mm. If the blade bore is larger than the spindle, use the correct hardened-steel bushing (reducer ring) that ships with the blade or is sold separately.

For machine-matched tooling, browse our Diamond Trapezoid Grinding Disc (JOY-TP-R3) for Floo... range.

Common Arbor Sizes

What you should know before starting.

Contractors who skip this stage usually end up redoing the floor.

A Practical Guide to Fit a Blade Correctly

The key points in practice.

• If bore > spindle: install the correct bushing first, then the blade.
• Read the bore size on the blade label or center stamp.
• Torque the flange nut to spec — under-tightening causes wobble.
• Read the spindle size on the saw spindle or manual.
• Spin the blade by hand to inspect it seats level on the flange.

This is where most crews get it right - or lose time.

When You Need an Adapter

A closer look at the details.

Our high-frequency welded blade ships with the common bore adapters, and the laser-welded range covers most floor saw spindle sizes.

Getting this part right saves a full re-pass later.

Safety Tips

What you should know before starting.

• Inspect the spindle for burrs before mounting system.
• Never run a blade with a loose bore — it can shatter.
• Replace bent or worn bushings.

Contractors who skip this stage usually end up redoing the floor.

Frequently Asked Questions

Q: Is it possible to use a 25.4 mm blade on a 20 mm arbor?

A: For most jobs, A>Yes, with the correct 25.4-to-20 mm bushing. Never run it without one.

Q: What exactly if my blade bore is smaller than the arbor?

A: In short, A>Do not force it or file it — return the blade for the correct bore size.

Q: Do I bushings affect balance?

A: The practical answer is, A>Quality hardened bushings are machined to tolerance and don't affect balance. Cheap cast washers do.

Q: How exactly do I know my saw's arbor size?

A: For most jobs, A>inspect the spindle with a ruler or the manual — most cut-off saws and grinders print it on the guard.

Looking for the right tool? Check our Single Rhombus Segment Diamond Trapezoid Grinding Di.... Looking for the right tool? Check our Double Rhombus Segment Diamond Trapezoid Grinding Disc.

Conclusion

Match the tooling to the concrete, keep the machine in good condition, and run even passes - the finish follows. A correctly fitted blade bore and bushing keep your saw safe and wobble-free.
